Nowadays, the competition in every industry in the society is very fierce, and the electronic connector industry is different from the past. There are more and more brands and companies making connectors, from the earliest FPC connectors to the current board-to-board connector specifications. And model output, the demand for connectors in the field still seems to be high, and the earliest FPC connections were stronger. Many people don't know much about what to look for when choosing a board-to-board connector and how to connect them.
The board-to-board connector is a product with the strongest transmission capacity among all connector products. The existence of board-to-board connectors not only facilitates disassembly, but also provides power and signal carriers for products. Board-to-board connectors are a must for connecting various components in all electrical and electronic products. Therefore, when designing electronic products, it is necessary to choose the appropriate connector, otherwise the connector will be too small and the whole system will fail.
Board-to-board connectors can be selected from the following directions
If you're willing to accept a smaller vacuum area, then you're right. To choose a subminiature connector, you must first check that the connector has the other properties you need, and test it carefully to make sure it's strong enough.
Requires selection of receptacles with top mount headers. Since this setup can be tracked under the socket, using conformal paint is made easy. Top mounted sockets have some drawbacks, the width of the vacuum pick-up area tends to be narrow, there is no plastic housing material above the socket terminals to prevent it from rising due to rude breaking action, and the uneven top surface of the socket can cause trouble for the operator in wiring operations . To achieve the desired locking function of these connectors, it may be necessary to tolerate the extra length of the connector.
The board-to-board connector is an important part of the entire electronic system design. It can be used in the design of products such as displays and LED lights. When choosing electronic components, we should not only pay attention to the chip technology, but also pay attention to the selection of peripheral components, so that the system can run smoothly, so as to achieve more with less effort.
